Detail BROYCE LMMT 24-230VAC 12-230VDC 48-63HZ MULTI FUNCTION MULTI VOLTAGE
BROYCE LMMT 24-230VAC 12-230VDC 48-63HZ MULTI FUNCTION MULTI VOLTAGE TIMER DIN RAIL HOUSING LMMT - GENUINE
Brand = BROYCE CONTROL
Type = LMMT
Description = Multi Function Multi Voltage Timer
Multi Voltage Input = 24 – 230VAC : 12 – 230VDC
*NEW* 17.5mm DIN rail housing
7 Selectable functions (3 Supply Initiated, 4 Switch Initiated)
3 Switch initiated functions are re-triggerable (DOb, DN and INb)
7 Selectable time ranges (0.1 seconds – 100 hours)
Fine adjustment of selected time range
LED warning indication if function is changed whilst powered
Switch initiated functions ideal for use in Watchdog circuits
Multi-voltage input (24 – 230V AC/12 – 230V DC)
1 x SPDT relay output 8A
Green LED indication for supply / timing status
Red LED indication for relay status
Conforms to IEC 61812
BROYCE CONTROL - GENUINE PRODUCT 100%
